| RANGE OF PERFORMANCE |
|
Flow rate up to 500 l/min (30 m3/h)
Head up to 15 m |
|
| LIMITS OF USE |
|
Depth up to 5 m
Liquid temperature up to + 40°C
Passage of suspended solid bodies up to Ø 50 mm
For continuous duty: minimum immersion 290 mm from pump base |
|
|
| INSTALLATION AND USE |
|
| THEY ARE RECOMMENDED FOR DOMESTIC, CIVIL AND INDUSTRIAL USE, IN APPLICATIONS WHERE THE WATER CONTAINS SUSPENDED SOLIDS WITH DIMENSIONS UP TO Ø 50 mm. THEIR USE IS RECOMMENDED FOR DRYING FLOODED AREAS SUCH AS CELLARS, UNDERGROUND CAR PARKS, CAR WASHING AREAS, OR DOMESTIC DRAINS AND FOR EMPTYING CESSPITS OR SEWAGE DISPOSAL. THESE PUMPS ARE OUTSTANDING IN THEIR RELIABILITY IN FIXED INSTALLATIONS WITH AUTOMATIC OPERATION. |
|
|
|
|
CONSTRUCTION CHARACTERISTICS |
|
|
- DELIVERY BODY: cast iron, with threaded port ISO 228/1.
- MOTOR CASING: stainless steel AISI 304.
- BASE: stainless steel AISI 304.
- IMPELLER: stainless steel AISI 304.
- MOTOR SHAFT: stainless steel EN 10088-3 - 1.4104.
- DOUBLE SEAL: mechanical seal silicon carbide - NBR, with oil barrier chamber and inner lip seal to protect the seal in the event of dry running.
- MOTOR: submersible asynchronous for continuous duty.
VXm: single-phase 220÷240 V - 50 Hz with capacitor and thermal overload protector.
VX: three-phase 380÷415 V - 50 Hz.
- INSULATION: class F.
- PROTECTION: IP 68.
STANDARD FEATURES:
VXm (single-phase) Float switch.
Neoprene power cable "H07 RN-F" length 5 metres with Schuko plug.
VX (three-phase) Neoprene power cable "H07 RN-F" length 5 metres.
|
|
|
|
- 10 metre power cable.
N.B. required for outdoor use to comply to standard EN 60335-2-41
- control panel for three-phase pumps 1.1 kW
- single-phase pumps without float switch
- other voltages or frequency 60 Hz
|
|
